Description
The Joint Protection Unit (BSZ) manufactured by KM GROUP is used in a wide range of fields. The units can be applied in:
- Electrochemical protection systems for the external surfaces of underground steel main pipelines used for transportation of natural gas, oil, and petroleum products, as well as their branches.
- Pipelines of compressor, gas distribution, pumping and booster stations, as well as oil depots.
- Critical components of oil and gas facilities, including tanks and well casing strings.
- Integrated gas and oil treatment facilities in underground gas storage sites.
- Main pipelines connected to pipelines of thermal power plants and other industrial sites that require corrosion protection.
- Systems for protection against soil corrosion of underground steel oil pipelines, gas pipelines, vessels, tanks, and other utility networks and structures in accordance with GOST R 51164 and GOST 9.602.
Joint protection units are designed for operation and protection of underground utilities and metal structures against electrochemical воздействия. In joint cathodic protection schemes, the joint protection unit (BSZ) performs the function of electrochemical protection of underground metal structures. They prevent the negative influence of neighboring underground metal structures on each other and are intended for electrochemical protection.
Various design types of BSZ joint protection units allow distribution of the rectifier output current among the protected structures and setting the optimal protective current for each of them. This ensures effective cathodic protection and prevents corrosion of metal structures. You can purchase joint protection units on the KM GROUP website.
When installing the BSZ protection unit, depending on the design, their operation is ensured under the following conditions:
- Outdoor installation (placement category 1 according to GOST 15150);
- Installation in shelters (placement category 2 according to GOST 15150).
BSZ units are manufactured in climatic versions U or UHL, corresponding to placement categories 1 or 2 in accordance with GOST 15150, thus maintaining operability under the influence of environmental climatic factors.
- For version U with placement categories 1 and 2, operability is ensured at temperatures from +45°C to −45°C;
- For version UHL with placement categories 1 and 2, operability is ensured at ambient temperatures from +40°C to −60°C and atmospheric pressure from 84.0 to 106.7 kPa (from 630 to 800 mm Hg).
Taking into account operating conditions and custom configurations, BSZ units are installed at the following facilities:
- in an electrical cabinet (Sh) providing the required enclosure protection level;
- as part of a structure associated with a test post (hereinafter referred to as ICP);
- in a waterproof enclosure (V) with protection rating IP67.
In addition, they may include the following elements:
- Digital or analog indicators, representing built-in measuring instruments or current monitoring devices;
- Devices integrated with corrosion monitoring systems;
- Other additional devices.
Thanks to a ready-made technical solution, BSZ.KMG can provide connection of two channel types: with “reverse” or with “direct” conductivity.
By regulation type, such units are classified as joint protection units of the following types:
- resistive (BSZD) with discrete manual current regulation;
- rheostat (BSZP) with smooth manual current regulation;
- electronic (BSZE) with smooth manual and/or automatic current regulation.
Anyone can purchase a BSZ unit on our website. We offer high-quality BSZ units of all types and provide delivery of required components on favorable terms throughout Kazakhstan and CIS countries.
